4500万像素12mm工业镜头C Mount

物距Working Distance

倍率Magnification

视野 1.4"Field of View(mm)

型号Model

SK1228MP45

mm

X

H

V

相机靶面Image Size

1.4”(18.96x12.86mm)

2000

0.0061X

3164.8

2132

焦距Focal length

12mm

1000

0.0121X

1598.9

1076.2

光圈范围F No.

F2.8-16

900

0.0134X

1442.1

970.5

最短物距M.O.D

0.1m

800

0.0151X

1285.4

864.9

控制方式Operation

Iris

Manual手动调整

700

0.0172X

1128.9

759.4

Focus

Manual手动调整

600

0.0200X

972.1

653.7

视场角Angle of View

(D×H×V)1.4"

86.8°×76.1°×55.7°

500

0.0238X

815.6

548.1

畸变Distortion

<0.5%

450

0.0264X

737.1

495.3

光学后焦BFL

11.7mm

400

0.0295X

658.8

442.4

接口Mount

C-Mount

350

0.0335X

580.4

389.6

近摄视野Object Dimension

502.0mm×336.8mm(WD=300mm)

300

0.0388X

502.0

336.8

外形尺寸Dimension

Φ57×68.3mm

250

0.0461X

423.6

283.9

滤镜尺寸Filter Thread

可选配M67xP0.75

200

0.0566X

345.2

231.1

分辨率Horizontal Resolution

45MP

150

0.0736X

266.6

178.2

工作温度Working Temperature

-20ºC ～ +60ºC

100

0.1050X

187.9

125.1
