45MP 12mm Large Format Lens SK1228MP45 Sensor 1.4-inch F2.8 C-Mount: 1.4″ C-Mount f=12mm F2.8; High resolution,higher illumination relative; Low distortion,Can suppress stray light; Achromatic optical system design; Compatible with visible and near infrared

View phone

Inquiry now

Tel:+86 13570283679

Introduction Specifications Download Other Product

※ Product Features
◆ Brand：ZLKC
◆ Image Size：1.4″ C-mount
◆ Focal length：f=12mm
◆ F No.：F2.8-16
◆ Features：1.4-inch Large Format Lens 12mm 45MP Manual Iris Lens C Mount HD Lens

※ Model
SK1228MP45

※ Dimension

※ Industries Application
These are used in machine vision and ITS monitoring. Excellent vibration resistance and stability at high and low temperature performance, optical axis shifting within pixel level,Maintain excellent optical properties at different object distances. These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C，traffic cameras and so on

45MP 12mm Low distortion FA Lens C Mount			Working Distance	Magnification	1.4"Field of View(mm)
Model		SK1228MP45	mm	X	H	V
Image Size		1.4″(18.96x12.86mm)	2000	0.0061X	3164.8	2132
Focal length		12mm	1000	0.0121X	1598.9	1076.2
F No.		F2.8-16	900	0.0134X	1442.1	970.5
M.O.D		0.1m	800	0.0151X	1285.4	864.9
Operation	Iris	Manual	700	0.0172X	1128.9	759.4
Operation	Focus	Manual	600	0.0200X	972.1	653.7
Angle of View (D×H×V)1.4"		86.8°×76.1°×55.7°	500	0.0238X	815.6	548.1
Distortion		<0.5%	450	0.0264X	737.1	495.3
BFL		11.7mm	400	0.0295X	658.8	442.4
Mount		C-Mount	350	0.0335X	580.4	389.6
Object Dimension		502.0mm×336.8mm(WD=300mm)	300	0.0388X	502.0	336.8
Dimension		Φ57×68.3mm	250	0.0461X	423.6	283.9
Filter Thread		Selectable M67xP0.75	200	0.0566X	345.2	231.1
Horizontal Resolution		45MP	150	0.0736X	266.6	178.2
Working Temperature		-20ºC ～ +60ºC	100	0.1050X	187.9	125.1

SK1228MP45 Specifications
