    FA Lens FM2028MP5 20mm Manual Iris Industrial camera Lens 2/3-inch F2.8 5MP C-Mount
    2/3″C-Mount f=20mm F2.8
    High resolution ,high clarity
    Can suppress stray light
    Low distortion,High measurement accuracy
    Locking set screws for focus and Iris
    compact appearance for device integration
    Lower price,higher performance
    View phone Inquiry now
    Tel:+86 13570283679
    IntroductionSpecificationsDownloadOther Product
    ※ Product Features
    ◆ Brand：ZLKC
    ◆ Image Size：2/3″ C-mount
    ◆ Focal length：f=20mm
    ◆ F No.：F2.8-16
    ◆ Features：2/3-inch 20mm Manual Iris Lens F2.8 C Mount FA Lens Industrial camera Lens

    ※ Model
    FM2028MP5

    ※ Dimension


    ※ Industries Application
    Suitable for Industrial Inspection . These cover applications from electronics and semiconductor SMT inspection and robotics to food inspection, postal sorting and inspections of printed images 3C and so on

    5MP 20mm FA Lens C Mount

    Model

    FM2028MP5

    Image Size

    2/3-inch

    Focal length

    20mm

    F No.

    F2.8-16

    M.O.D(m)

    0.2-Inf.

    Operation

    Iris

    Manual

    Focus

    Manual

    Angle of View

    (D×H×V)

    2/3"

    30.8°×24.8°×18.7°

    1/1.8"

    25.1°×20.3°×15.1°

    1/2"

    22.6°×18.2°×13.7°

    1/2.9"

    17.6°×15.4°×8.6°

    TV Distortion

    -0.38%

    BFL

    12.04mm

    Flange FL

    17.526mm

    Mount

    C-Mount

    Dimension

    Φ29×25.1mm

    Weight

    65.0g

     Resolution

    5.0MP

    Filter

    M27 P=0.5mm

    Working Temperature

    -20ºC ～ +60ºC

    FM2028MP5 Specifications
